Under normal circumstances, a good cutting quality of the power supply can provide higher accuracy of laser cutting machine, but even if use the same brand, same type of plasma power supply, different operators to cut out the parts quality is also different, the reason lies in the use of laser cutting machine power where there is a need to improve.
In addition, for laser cutting machine power radiation problem recently, there are many media reported how to render its harm to the environment is too serious, but the fact is, plasma cutting technology in the world already has nearly 30 years of development, the pollution impact also did not achieve the media described so bad, the reason to cause the domestic enterprises for laser cutting machine power supply using the misunderstanding, we think investigate its root lies in the domestic processing enterprises for the standardization of the laser cutting machine power use there is a deviation.This paper, edited by the technical department, gives a comprehensive description of the radiation maintenance of laser cutting machine power supply.
One, laser cutting machine power use process
Spare parts of laser cutting machine, plasma size and quality determines the laser cutting plate thickness and cutting accuracy, therefore, very important in the field of plasma power supply, with the development of related technologies, with CNC cutting machine price cut, the steady import plasma power supply and some domestic high-end plasma power prices to rise further, which to some extent reflects the dominant position of the plasma power supply in the numerical control cutting processing.
1. When cutting, try to set parameters according to the cutting table, such as arc pressure value, cutting height, perforation height, etc.;
2. Ensure enough gas pressure and flow rate, the pressure is not less than 9kg during normal cutting (airborne power supply is not less than 6kg), pay attention to the distance between the gas and the plasma host;
3. Maintain good electrical conductivity between the positive grounding clamp and the cut steel plate;
4. When the plasma cutting is not used temporarily, please ensure that the heat dissipation of the main engine is sufficient before the shutdown, subject to the reduction of fan noise in the main engine;
5. Open the shell of the main engine for dust removal every one and a half to two months (for example, blow with compressed air or dry with compressed air after cleaning with high-precision electronic component cleaning agent) to ensure the smooth completion of the main engine;
6. Ensure that the incoming line of the main engine is in 3 phase electric balance, and do not have phase deficiency or excessive pressure difference;
7. In case of insufficient cutting energy (such as penetrating steel plate, arc deviation or trailing), please stop immediately for inspection, and no further cutting is allowed;
8. Ensure good grounding of steel plate, the resistance of steel plate to absolute earth should not be more than 3 ohms;
9. Try not to suspend arc starting and perforation for a long time to improve the service life of wearing parts;
10. Ensure that the cutting gun is maintained at the highest point of the lifting position before each cutting, during the high-speed and low-speed running of the air journey, during the downtime for maintenance, and before the shutdown.
Two, laser cutting machine power maintenance skills
Laser cutting machine for metal USES the high temperature of plasma arc column to melt the cut material and blow away the parent material to form the slit.The radiation intensity of plasma electrolight is very high, which is mainly composed of ultraviolet radiation, visible light radiation and infrared radiation, especially ultraviolet intensity. For example, the relative intensity of ultraviolet radiation with wavelength of 260-290 m is 2.2 times that of argon arc welding.Harm to human body in addition to light radiation, there is smoke and other toxic gases, high intensity high frequency noise, high frequency oscillator generated by the high frequency cause harm to human body, so the plasma cutting machine operating position is a toxic and harmful level B jobs.
Plasma is a special form of matter that modern physics lists as the fourth state of matter after solid, liquid and gas.Plasma arc is a compression arc obtained by forced "compression" of free arc through mechanical compression, thermal compression and magnetic contraction. It has concentrated energy, high temperature (18000-24000K in the center of arc) and high flame velocity (up to 300m/s).
1. Unscrew the screws, remove the air filter and prepare for cleaning;
2. Regularly monitor the network voltage of the CNC system to ensure that the fluctuation range of the network voltage is within the allowable rated range;
3. Gently vibrate the removed filter and blow off the dust in the air filter with compressed air from inside out;
4. Regularly check and replace the brush of dc motor;
5. If the filter dust is too thick and the compressed air cannot be removed, the filter can be gently washed with neutral cleaner and dried in a cool place;
6. Replace the storage battery regularly.In general, batteries should be replaced annually to ensure that the system works properly, even if they have not yet failed.
